SPECIFICATIONS AND GENERAL INFORMATION
4241262-Rev B 2-9
2
Steering
Test and Adjustment Specifications
Rear Axle Alignment Toe-In Measurement in. (mm) 0.030–0.090 (0.8–2.3)
Rear Axle Steering Arm-to-Steering Stop
Measurement
in. (mm) 0.030–0.090 (0.8–2.3)
Rear Axle Assembly End Play
in. (mm) 0.010–0.060 (0.25–1.5 mm)
Repair Specifications
Steering Wheel Nut lb-ft (N·m) 25–30 (34–41)
Steering Unit End Cover-to-Housing Screw Torque
lb-ft (N·m) 20–24 (27–33)
Throttle Arm Screw Torque
lb-in. (N·m) 100 (11.3)
Throttle Stop Carriage Bolt Torque
lb-in. (N·m) 157 (17.7)
Steering Cylinder Ball Joint-to-Steering Arm Torque
lb-ft (N·m) 80–110 (108–149)
Tie Rod Ball Joint-to-Steering Arm Torque—
2WD Cutting Units
lb-ft (N·m) 30–35 (41–47)
Tie Rod Ball Joint-to-Steering Arm Torque—
4WD Cutting Units
lb-ft (N·m) 80–110 (108–149)
Steering Arm-to-Motor Mount Screw Torque
lb-ft (N·m) 90–100 (122–136)
Rear Axle Assembly Jam Nut Torque
lb-ft (N·m) 80–110 (108–149)
