TURFCAT T628D
Item Part No. Qty. Description Serial Numbers/Notes
1
340070 2 Fitting, -10 ORFS x -10 ORB 90°
339911 1 • O-Ring, -10 ORFS
339899 1 • O-Ring, -10 ORB
2 178112-09 1 Hose, Pump to Deck Valve
3 339989 2 Fitting, -10 ORFS x -10 ORB Straight
339911 1 • O-Ring, -10 ORFS
339899 1 • O-Ring, -10 ORB
4 339923 2 Cap, -10 ORFS
Caps removed when cutting unit is
installed.
5 340073 1 Fitting, -12 ORFS x -10 ORB 90°
339912 1 • O-Ring, -12 ORFS
339899 1 • O-Ring, -10 ORB
6 2692244-01 1 Hose, Deck Valve to Oil Cooler
7 339993 1 Fitting, -12 ORFS x -10 ORB Straight
339912 1 • O-Ring, -12 ORFS
339899 1 • O-Ring, -10 ORB
8 830930 2 Hose Clamp, 1/2 - 1-1/4” dia.
9 108091-11 1 Hose, 3/4” I.D. x 48” Long
10 4199840 1 Tube, Oil Cooler to Tank
11 367458 1 Hose Clamp, 3/4 - 1-3/4” dia.
12 2198255 1 Hose, Tank Return
13 326799 1 Hose Clamp, 2-1/2”
14 4228940 1 Test Fitting
15 2690016-01 1 Fitting, -10 ORB x 3/4” Barbed
339899 1 • O-Ring, -10 ORB
16 2692217-16 1 Hose, Cutting Unit Motor Return See 24.1 or 25.1
17 2692295-02 2 Hose, Deck Valve to Deck Motor 956023 - 60” Rear Discharge Only
17 2692295-03 2 Hose, Deck Valve to Deck Motor 956314 - 63” Side Discharge Only
17 2692295-04 2 Hose, Deck Valve to Deck Motor
957233 - 72” Side Discharge
957234 - 72” Rear Discharge
18 340059 1 Fitting, -6 ORFS x -4 ORB 90° 956023 - 60” Rear Discharge
956314 - 63” Side Discharge
957233 - 72” Side Discharge
957234 - 72” Rear Discharge
339909 1 • O-Ring, -6 ORFS
339896 1 • O-Ring, -4 ORB
19 2692238-06 1 Hose, Deck Valve to Flail Motor
956025 - 60” Flail Only
20 2692238-05 1 Hose, Flail Motor to Deck Valve
21 339977 1 Fitting, -6 ORFS x -4 ORB Straight
339909 1 • O-Ring, -6 ORFS
339896 1 • O-Ring, -4 ORB
22 2692286-02 1 Hose, Flail Motor Drain
23 2218152-05 1 Motor, 20.8 cc Cutting Unit
Parts included with and are
common to all cutting units
2218152-04 1 • Seal Kit
24 340070 2 Fitting, -10 ORFS x -10 ORB 90°
339911 1 • O-Ring, -10 ORFS
339899 1 • O-Ring, -10 ORB
