89
> Change from previous revision
TURFCAT T628D
Item Part No. Qty. Description Serial Numbers/Notes
1
65362-04 3 Rubber, Clamp 10” Length, Cut to fit clamp
2 326112 2 Clamp, Hose
3 326799 1 Clamp, Hose
4 108138-02 1 Hose Clamp 2WD Units Only
5 452390 1 Screw, M8-1.25 x 30 mm Hex Head 2WD Units Only
6 446136 1 Lockwasher, 5/16 2WD Units Only
7 400120 1 Screw, 1/4-20 x 2” Hex Head 4WD Units Only
8 452004 3 Flat Washer, 1/4 4WD Units Only
9 445770 2 Nut, 1/4-20 Hex Nylock 4WD Units Only
10 148090-03 2 Hose Support 4WD Units Only
11 450015 1 Screw, M8-1.25 x 35 mm Hex Head 4WD Units Only
12 2722141.7 1 Bracket, Hose 4WD Units Only
13 450378 1 Nut, M8-1.25 Hex Nylock 4WD Units Only
14 64123-105 1 Screw, 1/4-20 x 1-5/8” Hex Head
