91
> Change from previous revision
TURFCAT T628D
Item Part No. Qty. Description Serial Numbers/Notes
1
64123-133 2 Screw, 5/8-18 x 3” Hex Head
2 446166 2 Lockwasher, 5/8
3 443128 2 Nut, 5/8-18 Hex
4 64141-4 6 Nut, 3/8-16 Whiz Lock Flange
5 400262 2 Screw, 3/8-16 x 1” Hex Head
6 310711 2 Flat Washer, 3/8
7 23009A 2 Spacer
8 400266 2 Screw, 3/8-16 x 1-1/2” Hex Head
9 400190 2 Screw, 5/16-18 x 1-1/4” Hex Head
10 366653 2 Spacer
11 445816 2 Nut, 5/16-18 Nylock
12 2198162 2 Spring, Extension
13 2192762.7 2 Plate, Deck Stop
14 2192763.7 2 Bracket, Deck Stop Side Discharge Decks
14 2192777.7 2 Bracket, Deck Stop Rear Discharge Decks
15 64139-14 8 Screw, 5/16-18 x 7/8” Flange Head
16 64141-6 10 Nut, 5/16-18 Whiz Lock Flange
17 523126 2 Bumper, Rubber
To Next Page
