111
> Change from previous revision
TURFCAT T628D
Item Part No. Qty. Description Serial Numbers/Notes
2721560 1 Front Valve Plate Assembly
1 N/S 1 • Valve Plate
2 N/S 2 • Cap, Relief Valve
● 3N/S 2•O-Ring
4 4230540 2 • Relief Valve, 3625 psi
5 N/S 1 • Plug, #3
● 6N/S 1•O-Ring
7 N/S 2 • Pin, Locating
5003497 1 • Tow Valve Assembly
8 N/S 1 • • Stem, Tow Valve
● 9N/S 1••O-Ring
● 10 N/S 1 • • Backup Ring
11 N/S 1 • • Bonnet, Tow Valve
● 12 N/S 1 • • O-Ring
13 N/S 1 • • Nut, 3/8-24 Hex Jam
4215102 1 Gerotor and Coupling
14 N/S 1 • Coupling, Gerotor
15 N/S 1 • Ring, Retaining
16 N/S 1 • Assembly, Gerotor Pump
17 N/S 1 • Key, Gerotor Pump
4229540 1 Rear Valve Plate Assembly
18 N/S 1 • Cap, Relief Valve
● 19 N/S 2 • O-Ring
20 N/S 1 • Bushing, Coupling
21 N/S 2 • Plug, #3
● 22 N/S 2 • O-Ring
23 N/S 1 • Rear Plate
24 4230560 1 • Relief Valve, 915 psi Implement
25 N/S 1 • Cap, Charge Relief
4238983 1 • Charge Relief Valve Kit
26 N/S 1 • • Poppet, BPRV
27 N/S 1 • • Spring, 60 psi Relief
● 28 N/S 1 • O-Ring
● 29 N/S 2 • O-Ring
● Included in Seal Kit 4149859
To Next Page
