Jacobsen Turfcat T628D Parts & Maintenance Manual

115
> Change from previous revision
TURFCAT T628D
Item
Reference
Illustration
Part
Number
Description Serial Numbers/Notes
B1 N/S Battery Obtain Battery Locally
CB1 See 14.1 48524 40A Circuit Breaker
F1 See 14.1 148082-20 20A Fuse
K1 See 14.1 2722325 Interlock Relay
K2 See 14.1 2722325 Seat Delay Module Relay
K3 See 14.1 2722325 Fuel Relay
K4 See 14.1 2722325 Starter Relay
K5 See 14.1 2722325 PTO Disable Relay
K6 See 45.1 4134530 Deck Valve Solenoid Coil Part of Deck Valve 4135584
K7 Not Shown 2811021 Fuel Solenoid Part of Engine
K8 Not Shown 148387 Flow Divider Solenoid Optional 2WD Differential Lock
L1 See 6.1 178092-22 Alternator Light
L2 See 6.1 178092-22 Engine Oil Pressure Light
M1 Not Shown 557888 Starter Motor Part of Engine
R1 Not Shown 4177227 Glow Plugs Part of Engine
R2 See 17.1 148270 Temperature Sender
R3 See 19.1 2208073 Fuel Sender
SW1 See 6.1 2810269 Ignition Switch Part of Engine
SW2 See 5.1 4139450 Seat Switch
SW3 See 7.1 108208 Neutral Switch
SW4 See 6.1 4174684 PTO Switch
SW5 See 8.1 38382 Parking Brake Switch
SW6 See 17.1 2722389 Temperature Switch
SW7 Not Shown 554018 Engine Oil Pressure Switch Part of Engine
SW8 See 6.1 148061 Horn Button Optional Kit
SW9 Not Shown 2208099 Differential Lock Switch Optional 2WD Differential Lock
SW10 See 3.1 38383 PTO Enable Switch
SW11 See 8.1 38382 Parking Brake Interlock Switch
U1 Not Shown 2810354 Alternator Part of Engine
U2 See 14.1 48030N Hour Meter
U3 See 6.1 148032 Fuel Gauge
U4 See 6.1 148269 Temperature Gauge
U5 See 14.1 2188154 Seat Delay Module
U6 See 14.1 886425 Horn
