41
> Change from previous revision
TURFCAT T628D
Item Part No. Qty. Description Serial Numbers/Notes
1
2721878 1 Instrument Panel
2 2721631 1 • Decal, Instrument Panel
3 2810269 1 Ignition Switch REFERENCE SW1, See 47.1
4 NS 1 • Nut, Ignition Switch
5 2811020 1 • Key, Ignition Switch
6 4174684 1 Switch, PTO REFERENCE SW5, See 47.1
7 2198089 1 Lamp Holder
8 178092-22 2 • Lamp REFERENCE L1 and L2, See 47.1
9 188015 1 Oil Pressure Lens
10 2198088 1 Battery Lens
11 48517-02 1 Hole Plug, 5/8”
12 48517 1 Hole Plug, 1”
13 178092-13 2 Switch Hole Plug
14 148032 1 Fuel Gauge REFERENCE U4, See 47.1
15 148269 1 Temperature Gauge REFERENCE U3, See 47.1
16 2188178 1 Switch Retainer
17 148061 1 Horn Switch (Optional Kit) REFERENCE SW8, See 47.1
