45
> Change from previous revision
TURFCAT T628D
Item Part No. Qty. Description Serial Numbers/Notes
1
2721907 1 Brake Pedal
2 810149 1 • Rubber Bumper
3 2198129 1 • Brake Pedal Mat
4 2192308.7 1 Support, Left Side Brake Shaft
5 2192310.7 1 Support, RIght Side Brake Shaft
6 2192361.7 2 Clamp, Brake Support
7 548045 8 Screw, 1/4-20 x 3/4” Whizlock Flange
8 445784 8 Nut, 1/4-20 Whizlock Flange
9 548604 7 Screw, 5/16-18 x 3/4” Whizlock Flange
10 2722201.7 1 Parking Brake Lever
11 2192351.7 2 Bracket, Brake Lever
12 450170 1 Screw, M6-1 x 16 mm Hex Head
13 450377 1 Nut, M6-1 Hex Nyloc
14 143011 1 Link, Pedal
15 840476 1 Spring, Tension
16 461359 2 Roll Pin, 1/8 x 3/4”
17 38382 1 Parking Brake Switch, NO REFERENCE SW5, See 47.1
18 402122 2 Screw, #10-24 x 1” Slotted
19 444310 2 Nut, #10-24 Hex
20 38382 1 Parking Brake Interlock Switch, NO REFERENCE SW11, See 47.1
21 48228-07 1 Clip, Cable
To Next Page
