TURFCAT T628D
Item Part No. Qty. Description Serial Numbers/Notes
1
2721873 1 Frame Rail, Left Side
● 2 450359 3 • Insert, M8-1.25 Use Insert Tool 2196247
3 2721872 1 Frame Rail, Right Side
● 4 450359 6 • Insert, M8-1.25 Use Insert Tool 2196247
◆ 5 450367 2 • Insert, M6-1 Use Insert Tool 2196246
6 450215 10 Screw, M10-1.5 x 30 mm Hex Head
7 452008 24 Flat Washer, M10
8 450379 12 Locknut, M10-1.5 Nylon
9 450029 2 Screw, M10-1.5 x 35 mm Hex Head
10 2721874 1 Front Frame
11 148086 1 • Mat, Left Side Floor
12 148085 1 • Mat, Right Side Floor Not Shown
13 4181865 1 • Decal, Main Warning
14 2000743 1 • Decal, Brake Pedal
15 2000647 1 • Decal, Forward/Reverse
16 4113467 1 Front Axle
● 17 450359 2 Insert, M8-1.25 Use Insert Tool 2196247
18 2196132.6 1 Rear Frame
19 363386 4 Screw, M12-1.75 x 30 mm Hex Head
20 452010 8 Flat Washer, 1/2
21 450380 8 Locknut, M12-1.75 Nylon
22 450048 4 Screw, M12-1.75 x 40 mm Hex Head
23 2192586.7 1 Rear Bumper
24 2192304.7 AR Rear Weight 2WD Qty 11, 4WD Qty 8
25 441693 2 Carriage Bolt, 1/2-13 x 5”
26 444758 2 Locknut, 1/2-13 Nylon
27 2206030.7 1 Rear Axle Pivot
28 409812 4 Screw, 5/16-18 x 3/4 Thread Cutting
29 445820 1 Nut, 1-1/4-12 Nylock
30 REF 1 Rear Axle See 12.1(2WD), or See 13.1 (4WD)
31 361648 2 Thrust Washer
32 REF 1 Wheel Motor and Brake See 9.1
4242522 Wheel and Tire Assembly
33 4249870 2 • Tire, 23 x 10.5-12 4 Ply Multi Trac
34 4242523 2 • Rim, 12 x 8.5” with Valve
35 353914 10 Wheel Bolt, 1/2-20
4242525 2 Wheel and Tire Assembly 2WD Units
4242527 2 Wheel and Tire Assembly 4WD Units
36 4236020 2 • Tire, 18 x 9.5-8 4 Ply Rib Tread 2WD Units
36 4242528 2 • Tire, 18 x 8.5-8 4 Ply Turf Trac 4WD Units
37 4242526 2 • Rim, 8 x 7”
38 354807 8 Wheel Nut, 1/2-20
39 4194329 1 Decal, Patent Number 4WD Units Only
40 REF 1 Serial Plate
41 4117468 1 Decal, 105 dB Sound
42 AR Trim, 1/8” Channel Flex
To Next Page
