4/55
1. Introduction
SAFETY GUIDELINES – DEFINITIONS
SAVE THESE INSTRUCTIONS: This manual contains information for the proper
assembly, operation and care of your sprayer. Carefully read and follow the instruc-
tions contained in this manual before using your sprayer.
This equipment was designed for spraying plants protection products approved
by regulatory authorities to be used in knapsack sprayers.
The product may be subject to national requirements for regular inspection by
designated bodies, as provided for in Directive 2009/128/EC of the European
Parliament and of the Council of 21 October 2009 establishing a framework for
Community action to achieve the sustainable use of pesticides.
It is important for you to read and understand this manual. The information it
contains relates to protecting YOUR SAFETY and PREVENTING PROBLEMS. The
symbols below are used to help you recognize this information.
2. Specifications
3. General Power Tool Safety Warnings
Model PJB-20/16
Maximum dimensions (L x W x H)
390 mm x 200 mm x 553 mm
390 mm x 200 mm x 480 mm
Net weight 4.9 kg/ 4.8 kg
Gross weight 5.7 kg/ 5.5 kg
Spray lance length 600 mm
Hose length 1350 mm
Chemical tank
Capacity 20 L/ 16L
Residual volume None
Filling opening diameter 115 mm
Material Polyethylene
Pump
Type Diaphragm
Maximum pressure 60 psi (4,1 bar)
Open ow 2,1 L/min
Nozzle installed Blue adjustable nozzle
Battery
Type Lithium Ion, rechargeable
Rated Voltage 14.54 V (16.4 V max.)
Capacity 84.3 Wh (5800 mAh)
Recharge time 5h
Autonomy* 5 - 14h
WARNING!
Read all safety warnings and all instructions. Failure
to follow the warnings and instructions may result in
electric shock, re and/or serious injury.
DANGER!
Indicates an imminently hazardous situation which, if not avoided, will
result in death or serious injury.
WARNING!
Indicates a potentially hazardous situation which, if not avoided, could
result in death or serious injury.
NOTE: Used without the safety alert symbol indicates a potentially hazardous
situation which, if not avoided, may result in property damage.
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE.
The term “power tool” in the warnings refers to your mains-operated (corded)
power tool or battery-operated (cordless) power tool.
3.1. Work area safety
a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b. Do not operate power tools in explosive atmospheres, such as in the pres-
ence of ammable liquids, gases or dust. Power tools create sparks which
may ignite the dust or fumes.
c. Keep children and bystanders away while operating a power tool. Distrac-
tions can cause you to lose control.
3.2. Electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in any
way. Do not use any adapter plugs with earthed (grounded) power tools.
Unmodied plugs and matching outlets will reduce risk of electric shock.
b. Avoid body contact with earthed or grounded surfaces such as pipes, ra-
diators, ranges and refrigerators. There is an increased risk of electric shock if
your body is earthed or grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a pow-
er tool will increase the risk of electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or un-
plugging the power tool. Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase the risk of electric shock.
e. When operating a power tool outdoors, use an extension cord suitable
for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric
shock.
f. If operating a power tool in a damp location is unavoidable, use a ground
fault circuit interrupter (GFCI) protected supply. Use of a GFCI reduces the
risk of electric shock.
CAUTION!
Indicates a potentially hazardous situation which, if not avoided, may
result in minor or moderate injury.
3.3. Personal Safety
a. Stay alert, watch what you are doing and use common sense when oper-
ating a power tool. Do not use a power tool while you are tired or under
the inuence of drugs, alcohol or medication. A moment of inattention while
operating power tools may result in serious personal injury.
b. Use personal protective equipment. Always wear eye protection. Protec-
tive equipment such as dust mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce personal injuries.
c. Prevent unintentional starting. Ensure the switch is in the o-position be-
fore connecting to power source and/or battery pack, picking up or car-
rying the tool. Carrying power tools with your nger on the switch or energizing
power tools that have the switch on invites accidents.
d. Remove any adjusting key (wrench, screwdriver…) before turning the
power tool on. A wrench or a key left attached to a rotating part of the power
tool may result in personal injury.
e. Do not overreach. Keep proper footing and balance at all times. This en-
ables better control of the power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair,
clothing and gloves away from moving parts. Loose clothes, jewellery or long
hair can be caught in moving parts.
NOTE: See item “9.2. Pressure, ow rate and autonomy of each nozzle type”.
