J-200
A. 120V 3-Wire Connection (convertible models)
Figure D
(North American 60 Hz
120/240 VAC Convertible Models)
J31
J24 JUMPERS MUST BE IN
120V POSITIONS AS SHOWN
DEFAULT SETTING
J31 JUMPER MUST BE
ON 1 PIN WHEN HEATER IS
CONFIGURED AS 120VAC
DEFAULT SETTING
F3 FUSE MUST BE
A 0.16A SLO-BLOW FUSE
DEFAULT SETTING
TB1
1
2
3
1
2
J4
J8
J18
J51
J1
J27
J10
3
J20
J10
J12 J88
J52
J38
AV
J46
PUMP1
UV
OZONE
GFCI
GRN
WHT
BLK
0.16A SLO-BLOW
F3
120V 120V
240V
SWITCH #2 AND 3
SET TO OFF WHEN
HEATER IS
CONFIGURED
AS 120VAC
3
2
OFFON
HAND TIGHTEN WITH PHILIPS SCREWDRIVER.
WIRE STRIP LENGTH
11/16” (0.69”, 17.5mm)
BARE METAL
18
