Jacuzzi J-200 User Manual

J-200
A. Jumper wires for 1-Pump Convertible Models for a 4-Wire 240V
connection.
Location Device Volts Max Apms From To
J9 2-SP Pump 1 120V** 9A Max
J46 Area 3
J19
J21
UV
Ozone
120V** 0.5A Max
0.5A
UV and Ozone Line 1 connection J51, J52 Area 2
J33 TV / AV 120V 1.5A J38 Area 1
J15 Spa Light 10V 1A
J11 & J13 Heater 120V 1.0 kW @ 120V
(4.0 kW @240V)
120V-ONLY JUMPER WIRE* AREA 1 AREA 3
*REMOVE THIS JUMPER WIRE WHEN 240V IS USED (i.e. WHEN RED
INPUT WIRE IS USED)
**Pump 1, UV and Ozone all must be the same voltage.
60
