9.19 J-460 Massage / Waterfall Selector Diagram
L
K
1
4
4
1a
1a
1b
4
4
4
3
3 2
2
Massage Selector (1)
• Massage selector 1 diverts pump 1 output between jets groups 1a-1b.
Massage Selector (2)
• Massage selector 2 controls pump 1 output to footwell IX Jet.
Waterfall Selector (3)
• Waterfall selector 3 controls circulation pump output to waterfall.
Jets Without Massage Selector Controls (4)
• Jets 4 are always on when jets pump 2 is running.
