Jacuzzi J-470 User Manual

Page 15
J-400
Figure 6.0c (Terminal Block 230V/50z Wire Connection)
[refer to pages 83 and 84 for wiring diagram]
*IMPORTANT NOTE: Wire connections on controller
board must be changed depending on the number of
breakers being used, pages 89 and 90.
Blu
Brn
(N1)
(L1)
TB1
TB3
Green
Blu
Blu
Brn
Brn
Green
(L1)
(L2)
(N1)
(N2)
TB1
TB3
Blu
BrnBrn
Brn
Green
(L1)
(L2)
(N1)
(L3)
TB1
TB3
Service 1
Service 2
Brn (L2)
Brn (L1)
Blu (N2)
Blu (N1)
Service 1
Service 2
Service 3
Brn (L2)
Brn (L3)
Brn (L1)
Blu (N1)
Factory Default
Service 1
Brn (L1)
Blu (N1)

Jacuzzi J-470 Specifications

General

Pumps	2
Waterfalls	2
Shell Material	Acrylic
Cabinet Material	Synthetic
Dimensions	38 in
Water Capacity	450 gallons
Lighting	LED lighting system
Warranty	5 years
