Jacuzzi J-470 - J415;J425;J465;J470;J480 Export 50 Hz Wiring Diagram

Page 83
J-400
18.3 J415/J425/J465/J470/J480 Export 50Hz Wiring Diagram
Single service connection is the factory default.
NOTE: For a single service connection use TB1 locations B and C.
Additionally, the extra White wire must be installed.
see section 18.5
for dip switch settings
30A
K12
K9
K14
T1
3
2
TB1
D C B A
J22
MAIN PANEL CONNECTIONS
AV
F6
F2
UV
PUMP 2
J43
FUSE PUMP2/AV/UV
2.7KW HEATER
J51
J49
K11
K10
J59
J44
2A 250VAC
30A
FUSE PUMP1
PUMP 1
OZONE
CIRC PUMP
J27
F5
F4
J34 J29
J50 J56 J57
J37
K8
K4
K6
1/4AT 250VAC
WATER
TEMP
SERIAL ADCM
FLOW
HI-LIMIT
TEMP
J16
J17
J18
J1
J9
J11
J13 J14
J15
J10
J24
ZONE 2
J23
ZONE 1
J26
ZONE 4
C58 C57
K2
GFCI TRIP
J8
Q32
HEATER
J38
J53
J45
J46
J47
J41
J58
J42
J31
J32
J33
J40
J64
J36
J35
1
2
3
4
FUSE CIRC/OZONE
STATUS INDICATOR
GRN
J7 J69 J68
WI-FI
CONTROL PANEL
FLOW SENSOR
WATER SENSOR
BLUEWAVE STEREO
CLEARRAY
STEREO POWER SUPPLY
PUMP 2
PUMP 1
CIRC PUMP
HI-LIMIT SENSOR
STATUS INDICATOR
LEDS
L1 BRN N1 BLU
SINGLE SERVICE
STEP LIGHT (OPTIONAL) COLOR TOPSIDE
LIGHTING EXPANSION
LIGHT
J415 MODELS 230 VAC, 50Hz Single Service 22A, Dual Service 12A/10A
J425-J480 MODELS
230 VAC, 50Hz Single Service 29A, Dual Service 12A/17A Three Service 12A/10A/7A
ON
S1
1 2 3 4 5 6 7 8 9 10
S1
ON
1 2 3 4 5 6 7 8 9 10
