9.17 J-415 Massage/Waterfall Selector Diagram
100
6:45p
ON
2
1a
1a
1a
1a
1b
1b
2
b
a
1
Massage Selector (1)
• Massage selector 1 diverts output between jet groups 1a-1b.
Waterfall Selector (2)
• Waterfall selector 2 controls circulation pump output to waterfall.
