20 JacuzziSignatureWaterHeatersJ‐S180/J‐S199
ConnectElectricity
Donotrelyonthegasorwaterpipingtogroundthe
waterheater.Ascrewisprovidedinthejuncon box
forthegroundingconnecon.
Thewaterheaterrequires120VAC,60Hzpower
fromaproperlygroundedcircuit.
Onindoormodels,ifusingthe5footlong
power
cord,plugitintoastandard3prong120VAC,60Hz
properlygroundedwalloutlet.
Onoutdoormodels,adisconnectswitchmustbe
providedandinstalledfortheincoming120VAC
power.Itshouldbeatypethatissuitableforoutdoor
use.ChecktheNaonalElectrical
Code,ANSI/NFPA
70andyourlocalcodesforaproperswitchtypeto
useinyourarea.
ThewiringdiagramislocatedontheTechnicalSheet
aachedtotheinsideofthefrontcover.
WARNING
Donotuseanextensioncordoranadapterplugwith
thisappliance.
Thewaterheatermustbeelectricallygroundedin
accordancewithlocalcodesandordinancesor,inthe
absenceoflocalcodes,inaccordancewiththe
NaonalElectricalCode,ANSI/NFPANo.70.
Indoorwaterheatersareequippedwith
athree‐
prong(grounding)plugforyourproteconagainst
shockhazardandshouldbepluggeddirectlyintoa
properlygroundedthree‐prongreceptacle.Donot
cutorremovethegroundingterminalfr omthisplug.
ChecklistforGasandElectricity
□Amanualgascontrolvalveisplacedinthegas
linetothewaterheater.
□Checkthegaslinesandconnecons forleaks.
□Confirmthatthegasinletpressureiswithin
limits.
□Confirmthatthewaterheaterisratedforthegas
typesupplied.
□Confirmthattheelectricityissuppliedfrom120
VAC,60Hzpowersourceandisinaproperly
groundedcircuit.
□Anextensioncordoranadapterplughasnot
beenusedwiththewaterheater.
□Forindoormodels,verifythatswitchNo.1inthe
SW1DIPswitch(tanswitches)hasbeenadjusted
forventlengthifnecessary.Refertothesecon
onMaximumVentLength.
AdjustforHighAltude
OntheDIPswitch,setswitches2and3tothevalues
shownintablebelowforyouraltude.Thedefault
sengfortheapplianceis0‐2000(0‐610m)with
switchesNo.2andNo.3intheOFFposion.
WhentheDIPswitchisadjusted,
itisnotnecessaryto
adjustthegaspressuresengforhighaltude.
Altude
Switch
No.2
Switch
No.3
0‐2000(0‐610m) OFF OFF
2001‐5200(610‐1585m) OFF ON
5201‐7700(1585‐2347m) ON OFF
7701‐10200(2347‐3109m) ON
ON
AdjustforVentLength
(indoormodelsonly)
AdjustswitchNo.1intheSW1DIPswitch(tan
switches)ifrequired.Refertothesecon“Maximum
ventlength”.
