4 JacuzziSignatureWater HeatersJ‐S180/J‐S199
Alicensedprofessionalshouldinstalltheappliance,
inspectit,andleaktestitbeforeuse.Thewarranty
willbevoidedduetoimproperinstallaon.
Theinstallershouldhaveskillssuchas:
• gassizing
• connecnggaslines,waterlines,valves,
electricity,
• knowledgeofapplicablenaonal,state,and
localcodes.
• installingvenngthroughawallorroof
Ifyoulacktheseskillscontactalicensedprofessional.
InstallaonInstrucons
InstallaonSteps
 PrepareforInstallaon......................................5
 DetermineInstallaonLocaon........................6
 ChecklisttoDetermineInstallaonLocaon...12
 MounttoWall..................................................12
 RemovetheFrontPanel..................................12
 InstallaonofVenng(Indoormodels)...........13
 Condensate(Indoormodels)...........................15
 ChecklistforVenngandCondensate
 (Indoormodels)...............................................15
 InstallaonofPlumbing...................................16
 ChecklistforPlumbing.....................................18
 InstallaonofGasSupply................................18
 ConnectElectricity...........................................20
 AdjustforHighAltude...................................20
 AdjustforVentLength.....................................20
 Checklist
forGasandElectricity.......................20
 InstallaonofTemperatureController............21
 FinalChecklist..................................................22
GeneralInstruconsInstallerQualificaons
DONOT
• DonotinstalltheJ‐SN180F,J‐SP180F,J‐SN199F,or
J‐SP199Foutdoors.
• DonotinstalltheJ‐SN180W,J‐SP180W,J‐SN199W,
orJ‐SP199Windoors.
• Donotinstalltheapplia nce inanareawherewater
leakageoftheunitorconneconswillresultin
damagetotheareaadjacenttotheapplianceorto
lowerfloorsofthestructure.Whensuchlocaons
cannotbeavoided,itisrecommendedthata
suitabledrainpan,
adequatelydrained,beinstalled
undertheappliance.Thepanmustnotrestrict
combusonairflow.
• Donotobstructtheflowofcombusonand
venlaonair.Combusonairshallnotbe
suppliedfromoccupiedspaces.
• Donotusethisapplianceinanapplicaonsuchas
apoolorspaheaterthatuseschemicallytreated
water.(Thisappliance is suitableforfillinglargeor
whirlpoolspatubswithpotablewa ter.) 
• Donotusesubstutepartsthatarenotauthorized
forthisappliance.
MUSTDO
• Theinstallaonmustconformwithlocalcodesor,
intheabsenceoflocalcodes,withtheNaonal
Fuel Gas Code, ANSI Z223.1/NFPA 54.Ifinstalledin
amanufacturedhome,theinstallaonmust
conformwiththeManufactured Home
Construcon and Safety Standard, Title 24 CFR,
Part 3280.
• Theappliance,wheninsta lled,mustbeelectrically
groundedinaccordancewithlocalcodesor,inthe
absenceoflocalcodes,withtheNaonal Electrical
Code, ANSI/NFPA 70.
• Theapplianceanditsappliancemaingasvalve
mustbedisconnectedfromthegassupplypiping
systemduringanypressuretesngofthatsystem
attestpressuresinexcessof1/2psi(3.5kPa)
(13.84inW.C.).
TypeofInstallaon
• Forinstallaoninresidenalandcommercial
applicaons.
• Cerfiedforinstallaoninmanufactured(mobile)
homes.
