22 JacuzziSignatureWaterHeatersJ‐S180/J‐S199
FinalChecklist
□
Thewaterheaterisnotsubjecttocorrosive
compoundsintheair.
□ Thewatersupplydoesnotcontainchemicalsor
exceedstotalhardnessthatwilldamagetheheat
exchanger.
□ Clearancesfromthewaterheaterunitaremet.
□ Clearancesfromtheventterminaon/airintake
aremet.
□ Forindoormodels,ensureyouhaveusedthe
correctvenngproductsforthemodelinstalled
andthatyouhavecompletelyfollowedthe
venngmanufacturer’sinstallaoninstrucons
andtheseinstallaoninstrucons.
□ Forindoormodels,verifythattheventsystem
doesnotexceedthemaximumlength forthe
numberofelbowsused.
□ Forindoormodels,verifythatswitchNo.1inthe
SW1DIPswitch(tanswitches)hasbeenadjusted
forventlengthifnecessary.Refertothesecon
onMaximumVentLength.
□ Forindoormodels,verifythattheventpipehasa
downwardslopeorgradetotheoutsideof1/4
inchperfoot(1.2º)ORiftheventpipeissloped
towardthewaterheater(assomelocalcodes
require),thatacondensatecollectorisinstalled
toallowcondensaonto
drainawayfromthe
waterheatertoaproperdrainsource.
□ Forindoormodels,verifythatcondensatewillnot
beallowedtodrainbackintothewaterheater.
□ Purgethewaterlineofalldebrisandairby
closingthehotisolaonvalveandopeningthe
coldisolaonvalveanditsdrain.Debriswill
damagethewaterheater.Useabucketorhose
ifnecessary.
□ Ensurethathotandcoldwaterlinesarenot
crossedtotheunitandareleakfree.
□ Cleantheinletwaterfilterbyclosingthecoldand
hotwaterinletisolaon(shut‐off)valves.Puta
bucketunderthefilterattheboomofthewater
heatertocatchanywaterthatiscontainedinside
theunit.Unscrewthewaterfilter.Rinsethe
filtertoremoveanydebris.Installthefilterand
opentheisolaonvalves.
□ Ensurethatapressurereliefvalveisinstalledwith
arangthatexceedstheBTUinputofthewater
heatermodel.Refertotherangplateonthe
sideofthewaterheaterforBTUinput.
□ Amanualgascontrolvalvehasbeenplacedinthe
gaslinetothewaterheater.
□ Checkthegaslinesandconneconsforleaks.
□ Confirmthatthegasinletpressureiswithin 
limits.
□ Confirmthatthewaterhe ater is ratedforthegas
typesupplied.
□ Confirmthattheelectricity is suppliedfroma120
VAC,60Hzpowersource,isinaproperly
groundedcircuit,andturnedon.
□ Verifythetemperaturecontrollerisfunconing
properly.
□ VerifythatswitchesNo.2andNo.3intheSW1
DIPswitch(tanswitches)aresetcorrectlyfor
youraltude.
□ Verifythesystemisfunconingcorrectlyby
connecngyourmanometertothegaspressure
testportonthewaterheater.Operateallgas
appliancesinthehomeorfacilityathighfire.The
inletgaspressureatthewaterheatermustnot
dropbelowthatlistedonthe
rangplate.
□ Ifthewaterheaterisnotneededforimmediate
use,thendrainthewaterfromtheheat
exchanger.
□ Installthefrontpanel.
□ Explaintothecustomertheimportanceofnot
blockingtheventterminaonorairintake.
□ Explaintothecustomertheoperaonofthe
waterheater,safetyguidelines,maintenance,and
warranty.
□ Theinstallaonmustconformwithlocalcodesor,
intheabsenceoflocalcodes,withtheNaonal
Fuel Gas Code, ANSI Z223.1/NFPA 54.Ifinstalled
inamanufacturedhome,theinstallaonmust
conformwiththeManufactured Home
Construcon and Safety Standard, Title 24 CFR,
Part 3280.
□ Leavetheenremanualtapedtothewater
heater(indoormodels),temperaturecontroller
(outdoormodels),orgivetheenremanual
directlytotheconsumer.
