8 JacuzziSignatureWaterHeatersJ‐S180/J‐S199
AddionalClearances(IndoorModels)
24"
V
Checkonwhetherlocalcodessupersedetheseclearances.
• Avoidterminaonlocaonsnearadryervent.
• Avoidterminaonlocaonsnearcommercial
cookingexhaust.
• Youmustinstallaventterminaonatleast12
inchesfromtheground
60"
V
V
(1.52m)
between
terminalsat
differentlevels
(0.61m)towallorparapet

(0.30m)between
terminalsatsame
level
12"
V V
(1.52m)vercally
betweenterminals
V
60"
V
12"
12"
36"
INSIDE
CORNER
VV
(0.30m)to
aninside
corner
(0.30m)between
terminalsatsame
level

Importantconsideraonsforlocangvent
terminaonunderasoffit(venlatedorunvenlated)
oreavevent;ortoadeckorporch
• Donotinstallventterminaonunderasoffitvent
suchthatexhaustcanenterthesoffitvent.
• Installventterminaonsuchthatexhaustand
risingmoisturewillnotcollectunder
eaves.Discoloraontotheexteriorofthe
buildingcouldoccurifinstalledtooclose.
• Donotinstalltheventterminaontooclose
underthesoffitwhereitcouldpresent
recirculaonofexhaustgasesbackintothe
combusonairintakepartoftheterminaon.
