Page 22 of 32 IS2303VSP3J Rev-A
19. + - Use to set selected password character
< > Move to next password character
Note: When password protection is enabled and the timeout has elapsed, the user will be prompted to enter the
password to unlock the display when any of the display buttons (other than Stop/Resume) are selected. The user may use
Stop/Resume to stop the pump and resume normal operation without having to enter the password. The factory default
password is 1234. If the password has been changed, it may be reset to factory default by pressing and holding the Speed 1
and Speed 4 buttons at the same time while powering on the drive, or by resetting all parameters in the Configuration
Menu. If a mistake is made when entering the password, pressing Stop/Resume will cancel the action. If the pump is being
controlled by a Hayward or third party pool control, the pump display can be locked by the password, however, the pump
will respond to any and all commands being sent from the pool control.
Buttons
Screen Used Comments
20. + - Use + to reset to factory default settings
< > Use > to skip reset
21. + - Confirm reset of all parameters
< > Move to next menu item
22.
6.7. Timer Menu
Buttons
Screen Used Comments
1. < > Use > to enter Timer Menu
2.
3.
4. + - Use + to change displayed timer
< > Use > to skip to next timer
5. + - Use + to rename timer
< > Use > to set motor speed for timer
6. + - Use to set speed for timer
< > Use > to set start/stop time
7. + - Use to set start/stop time for timer
< > Use > to choose days of operation for timer
Timer Menu
Press > to enter
Timer 1 1725rpm
12:00a to 11:45p
Press + to change
or > next timer
T1: Timer 1
+/- rename; speed >
Timer 1 1725rpm
+/- adjust; times >
Timer 1 1725rpm
8:00a to 6:00p
Reset all settings?
+ yes or - no
Use Timers Menu to
set daily timers
Are you sure?
+ yes or - no
System Locked
Password: 0___
Press +/- to change
or > view next item
