Page 23 of 32 IS2303VSP3J Rev-A
8. + - Use to choose days of operation for timer
< > Move to next menu item
Note: When start/stop times are set to be the same, the timer is deactivated. Each timer can be set to run on specific
days of the week. Options are to run 7 days per week, 5 days per week (Monday thru Friday), or on a single day (Monday
thru Sunday). Each timer is set up in this same manner. If the timers are set up such that their run times overlap, the timers
will run in priority from Timer 1 to Timer 8. In other words, if Timer 1 is set to run from 8:00 am to 12:00 pm, and Timer
2 is set to run from 10:00 am to 2:00 pm, the pump will run Timer 1 from 8:00 am to 12:00 pm, and will then switch to run
Timer 2 until 2:00 pm. Default setting for Timer 1 is to start at 12:00 am, and end at 11:45 pm. When Remote Control
Mode is set to Relay Control, the speed for Timer 1 may be set to 0 rpm to allow the pump to be stopped without having
to remove power.
6.8. Preset Speed Setup Menu
Buttons
Screen Used Comments
1. < > Use > to enter Speeds Menu
2.
3.
4. + - Use to change displayed speed
< > Move to next menu item
5. + - Use to rename speed
< > Move to next menu item
6. + - Use to set motor speed for displayed speed
< > Move to next menu item
Note: Preset Speed settings can also be quickly updated without entering the Speeds Menu using the + and - arrow
buttons to change the speed and then pressing the > button to save the new speed setting.
Choose Days
7D 7 days a week
Speeds Menu
Press > to enter
Press + to change
or > next speed
Speed 1
S1: Speed 1
+/- rename; > speed
Speed 1 1725rpm
+/- adjust
Press +/- to change
or > view next item
To Next Page
