10.2. Parts Listing
Ref.
No.
Part No.
Description
Qty.
1
SPX2300DLSDB
Strainer Cover Kit (Includes Strainer Cover, Lock-Ring & O-Ring)
1
2
SPX2300Z4
Strainer Cover O-Ring
1
3
SPX2300M
Strainer Basket
1
4
SPX2300AALB
Pump Strainer Housing with Drain Plugs
1
5
SPX4000FG
Drain Plug with O-Ring
2
6
SPX2700ZPAK
Hardware Pack (Incl. 4 Housing Bolts, Seal-Plate Spacers & Square Nuts)
1
7
SPX2300Z3PAK3
Diffuser Screws (3 Pack)
1
8
SX220Z2
Diffuser O-Ring
1
9
SPX2300B
Diffuser
1
10
SPX2710CM
Impeller
1
11
GMX600F
Housing O-Ring
1
12A
SPX2700SA
Shaft Seal Assembly
1
12B
SPX2700SAV
Shaft Seal Assembly (Viton)
1
13
SPX2300ELB
Seal Plate
1
14
SPX3200Z5PAK4
Motor Bolt (4 Pack)
1
15
SPX2300GV
Motor Support (VSP) with Base Mount Screws
1
16
SPX1600Z52
Motor Support Base Mount Screws
1
17
SPX2700UNKIT
Union Connector Kit (Includes 2 Nuts, Connectors & Gaskets)
1
18
SPX3200LCDDB
Digital Control Interface Assembly
1
19*
SPX2300GR
Optional Riser Base Aligns with Sta-Rite® Dyna-Pro®
1
-
SPX3400DRKIT
Wall Mount Kit
1
-
SPX3200DRCC
Comm Cable Kit
1
-
SPX2300MRBPAK5
Basket Strainer Insert, Set of 5
5
POWER END
20
SPX2303Z1VSPE
Power End Assembly (Includes #7-14, Motor & Drive)
1
* Sta-Rite and Dyna-Pro are registered trademarks of Pentair Aquatic Systems, which are used herein for identification
purposes only. This is a retrofit base for existing Sta-Rite and Dyna-Pro pump installations.
