ENGLISH
SPECIFICATIONS
Important: Read complete instructions before beginning installation.
Each bath arrives ready for installation, completely equipped with blower motor, pump/motor assembly, heater, and plumbing
necessary for operation.
Remove the bath from the carton. Retain the shipping carton until satisfactory inspection of the product has been made. Do
not lift the bath by the plumbing or wiring at any time; handle by the shell only.
Immediately upon receipt, inspect the shell before installing. Should inspection reveal any damage or defect in the fi nish,
do not install the bath. Damage or defect to the fi nish claimed after the bath is installed is excluded from the warranty. Jacuzzi
Whirlpool Bath's responsibility for shipping damage ceases upon delivery of the products in good order to the carrier. Refer any
claims for damage to the carrier. For defi nitions of warranty coverage and limitations, refer to the published warranty information
packed with the product.
All bath units are factory tested for proper operation and watertight connections prior to shipping. NOTE: Prior to installa-
tion, the bath must be fi lled with water and operated to check for leaks that may have resulted from shipping damage
or mishandling. Jacuzzi Whirlpool Bath is not responsible for any defect that could have been discovered, repaired, or avoided
by following this inspection and testing procedure.
DRAIN/OVERFLOW
A
B
RECTANGULAR BATHS
5
Jacuzzi Whirlpool Bath EL21000B 10/06
END VIEW
SIDE VIEW
2"
(Inlet Heater)
(Motor)
(51 mm)
(Blower)
L
W
H
BELLAVISTA™
END VIEW
H
W
SIDE VIEW
L
1/2"
(13 mm)
(Motor)
(Inlet Heater)
(Blower)
ELARA
B
A
FUZION™
DRAIN/OVERFLOW
72"
26-1/2"
2"
1"
47"
SIDE VIEW
END VIEW
(51 mm)
(Inlet Heater)
(Motor)
(Blower)
(25 mm
SABELLA™
END VIEW
25"
42
"
SIDE VIEW
72
"
2"
(51 mm)
(Inlet Heater)
(Motor)
(Blower)
REÁL™
