Jacuzzi SALON User Manual

ENGLISH
9
Jacuzzi Whirlpool Bath EL21000B 10/06
ROUGHING-IN REFERENCE
NOTE: 1. THE OVERALL DIMENSIONS ARE NOMINAL WITH A TOLERANCE OF +0 AND -1/4" (6,4 mm).
2. Measurements inside each unit represent cutout in fl oor to allow for drain/overfl ow.
3. All measurements are in inches. To convert to millimeters, multiply inches by 25.4.
4. Service Access dimensions given are minimum size.
7"
32-1/2"
11-3/4"
6"
30-1/8"
42"
60"
4" x 4"
Motor
12" H x 24" L
Service Access
Heater
Blower
Bellavista™ 5,
(Right Hand Only)
10"
35-1/2"
11-3/4"
6"
30-1/8"
42"
66"
4" x 4"
Motor
12" H x 24" L
Service Access
Heater
Blower
Bellavista™ 5.5
(Right Hand Only)
4" x 4"*
42"
72"
10-1/2"
35-13/16"
11-3/4"
6"
30-1/8"
Motor
12" H x 24" L
Service Access
Heater
Blower
Bellavista™ 6
(Right Hand Only)
36"
42"
72"
11-7/8"
10" x 4"
2"
Motor
12" H x 24" L
Service Access
5-3/8"
Blower
Heater Blank*
MITO™ 6,
(Right hand only)
*MITO™ 6 COMES WITH HEATER BLANK ONLY.
INLINE HEATER MUST BE PURCHASED SEPARATELY.
60"
42"
21"
4.2"
9.6"
12" x 4"
2"
Heater
Motor
Opt. Service
Access
12" H x 24" L
Service Access
Blower
Elara™ 6042,
Right Hand
Elara™ 6636,
Right Hand
66"
36"
18 "
4.2"
9.6"
12" x 4"
Motor
Opt. Service
Access
12" H x 24" L
Service Access
Heater
2"
Blower
Some tubs are supplied with cutout template and/or undermount template. Refer to CUTOUT on pages 6-8 for template part
numbers.
72"
42"
21"
4.2"
9.6"
12" x 4"
2"
Heater
Motor
Opt. Service
Access
12" H x 24" L
Service Access
Blower
Elara™ 7242,
Right Hand
