Ⅵ. Interface of peripheral devices
6-1 RS-232 specification
The standard RS-232 interface is the 9-pin joint located at the rear-right of SNUG III; pin 2
is for signal output, and pin 5 is for grounding, and other pins are in reserve.
BAUD RATE：2400 OR 4800 OR 9600 bps
DATA BIT： 8
PARITY BIT：N﹝NONE﹞
STOP BIT：1
CODE：ASCII
BIT FORMAT：
LSB MSB
0 1 2 3 4 5 6 7
START BIT DATA BIT STOP BIT
DATA FORMAT：
N/G/T . W . : +/- LF CR
SP WEIGHT SP UNIT
N.W：Net weight
G.W：Gross weight
T.W：Tare weight
SP：SPACE
