Illustration 1 Illustration 2
Lower-most (bottom) racks for hanger types 2
and 3 must have the 4 “nibs” (if present)
removed from the lowest racks.* For Type 3
hangers, the upper rack “nibs” must also be
removed. For Type 2 hangers, leave the
“nibs” in place for the middle and top
positions. For Type 1 hangers, nibs can be left
in place (no removal necessary).
For hanger types 2 and 3 only, the
lowest (bottom) pair of hooks on
each hanger must be bent closed
around the lower rack side rails.
This is not required for Type 1
hangers.
* Remove the nib by using a
large, adjustable wrench.
Tighten the wrench jaws
around the nib and bend the
nib upward and downward
until it snaps off.
Hooks or
pegs go
here for
Type 1
Model 1300E Rack
Model 700E Rack
Model 700E Type 1 Model 700E Type 2 Model 700E Type 3 Model 1300E
