J&W X48 Series User Manual

- 32 -
Intel X48 Series User's Manual
4.5.7 JUSTw00t! Setting(OverClock Settings)
BIOS SETUP UTILITY
Main Advanced Boot Security Power JUSTw00T! Exit
Over Voltage and Clock Settings Allows BIOS to Select
ClockGenerator Mode
in Linear or Table.
←
Select Screen
↑↓
Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
CPU Boot Frequency : 1.60GHz (266x6)
CPU Adjust Frequency: 1.60GHz (266x6)
O.C Control
CPU FSB Frequency
O.PCIE Control
PCIE Frequency
FSB Strap to NorthBridge
CPU Sprend Spectrum
PCIE Sprend Spectrum
[Auto]
[266]
[Auto]
[100]
[Auto]
[Auto]
[Auto]
------------Please set DRAM Timming-------------
DRAM Boot Frequency : 667MHz [ Single Channel ]
DRAM Adjust Frequency: 400MHz
DRAM Frequency
Performance Level
[Auto]
[Auto]
DRAM Boot Timming : DDR2-5-5-5-15-7-36-11-3-3
Configure DRAM Timing [Auto]
--------Please Adjust MainBoard Voltage---------
CPUCore Voltage Detected :1.0100 V
DIMM Voltage Detected :1.888 V
CPU Voltage Control
DIMM Voltage Control
NB Voltage Control
CPU VTT Voltage Control
CPU PLL Voltage Control
SBCore Voltage Control
SB IO Voltage Control
MCH GTL Reference
HSWING Reference
CPU GTL Reference
Onboard Debug LED
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
v02.61 (C)Copyright 1985-2006, American Megatrends, Inc.
・
CPU Boot Frequency
Displays current CPU frequency.
・
CPU Adjust Frequency
Displays Adjust CPU frequency.
・
O.C Control
Overclock control, Optional:Auto, Manual
・
O.PCIE Control
PCIE Clock Setting,Optional:Auto
，
Manual
・
FSB Strap to NorthBridge
Setup the frequency for FSB Strap to NorthBridg
Optional
：
Auto
，
Strap 200MHz
，
Strap 266MHz
，
Strap 333MHz
，
Strap 400MHz
