H0285700 A

Installation and

Operation Manual

Jandy

®

CS Single

Element Cartridge

Pool and Spa Filters

Models

CS100 and CS150

WARNING

FOR YOUR SAFETY - This product must be installed and serviced by a professional pool/

spa service technician. The procedures in this manual must be followed exactly. Improper

installation and/or operation can create dangerous high pressure which can cause the lter

lid to be blown off, possibly causing death, serious injury or property damage. Improper

installation and/or operation will void the warranty.

Before installing this product, read and follow all warning notices and instructions that

accompany this lter. Failure to follow warning notices and instructions may result in

property damage, serious injury, or death.

Installation and Operation Data
