H0291800C
Installation and
Operation Manual
Jandy
®
Cartridge
Pool Filters
CL and CV Versa-Plumb
™
Series Filters
WARNING
FOR YOUR SAFETY - This product must be installed and serviced by a professional pool/
spa service technician. The procedures in this manual must be followed exactly. Improper
LQVWDOODWLRQDQGRURSHUDWLRQFDQFUHDWHGDQJHURXVKLJKSUHVVXUHZKLFKFDQFDXVHWKH¿OWHU
lid to be blown off, possibly causing death, serious injury or property damage. Improper
installation and/or operation will void the warranty.
Before installing this product, read and follow all warning notices and instructions that
DFFRPSDQ\WKLV¿OWHU)DLOXUHWRIROORZZDUQLQJQRWLFHVDQGLQVWUXFWLRQVPD\UHVXOWLQ
property damage, serious injury, or death.
b
™
Installation and Operation Data

Table of Contents

Questions and Answers

  • G
    Gina GeorgeAug 4, 2025
    How to fix low water flow in Jandy Versa-Plumb CL?
    • S
      Shannon NortonAug 4, 2025
      Low water flow in your Jandy Water Filtration System can be caused by several issues. Start by checking and cleaning the filter system strainer baskets. Inspect all connections between the pool intake and pump for air leaks. Look for restrictions or blockages in the suction or return lines, ensuring all lines are free of debris and valves are fully open. Clean or replace the filter cartridges as per the instructions. Ensure the pool water level is above the pump inlet line. Prime the pump by filling it with water at the basket and replacing the lid. Note that blocked pump impeller vanes or the pump operating under speed (low voltage) require a technician or electrician.
  • J
    Jeffrey StevensAug 10, 2025
    Why is my Jandy Water Filtration System water not clear?
    • D
      Daniel RodgersAug 10, 2025
      Unclear water in your Jandy Water Filtration System can stem from several factors. It could be due to an insufficient disinfectant level, which requires checking and adjustment. Incorrect pool chemistry also plays a role and needs testing and adjustment. Heavy usage or dirt loads might necessitate adjusting the filter time or water chemistry. Insufficient running times require increasing the pump run time. A dirty filter needs cleaning as per the instructions, and a hole in the filter element means the cartridge must be replaced.
  • C
    Cynthia ValenciaAug 16, 2025
    What to do if Jandy Versa-Plumb CL have short filter cycles?
    • H
      Hector SharpAug 16, 2025
      Short filter cycles in your Jandy Water Filtration System can arise from a few reasons. Algae clogging the filter may be the cause, so check the disinfectant content. Incorrect water chemistry, specifically pH, total alkalinity, and TDS, should be examined. The pump output might exceed the filter's design flow rate, requiring a check of pump performance. Ineffective cleaning could also be the culprit, so clean or replace the filter cartridge as instructed.
  • K
    Kathy EdwardsAug 22, 2025
    Why is there high pressure on start-up in my Jandy Water Filtration System?
    • J
      Jason BryantAug 22, 2025
      High pressure at start-up in your Jandy Water Filtration System may be due to a few reasons. A small eyeball fitting in the Pool/Spa can cause this, and you should replace it with a larger diameter fitting. A partially closed valve on the return line could also be the issue; check and fully open all valves on the return line. It's also possible the pump is too large, so verify the pump and filter selection. Lastly, dirty filter cartridges can lead to high pressure, so clean them as per the instructions.
  • E
    Eric LewisAug 27, 2025
    How to stop dirt returning to pool from Jandy Versa-Plumb CL Water Filtration Systems?
    • H
      harperalexanderAug 28, 2025
      If dirt returns to the pool from your Jandy Water Filtration System, it could be due to a hole in the filter cartridge, requiring you to replace the filter cartridge as per the instructions. Alternatively, a worn o-ring seal inside the filter might be the cause, in which case you should replace the o-ring.

Summary

Section 1. Safety Information

1.1 Important Safety Warning

Critical safety warnings regarding system pressure, air, and operational limits.

1.2 General Safety Instructions

Essential guidelines for safe installation, operation, and maintenance of the pool filter system.

Section 3. Installation Instructions

3.1 Filter Location

Guidance on selecting an appropriate and safe location for filter installation.

3.2 Anchor Bracket Installation

3.4 Filter Plumbing

Detailed instructions for connecting the filter to the pool's plumbing system.

3.5 Clamp Installation

Section 4. Start-Up and Operation

Section 5. Filter Disassembly and Assembly

Section 6. Maintenance

6.1 General Maintenance

6.2 Pressure Gauge

6.3 Cleaning the Filter Cartridge

Section 8. Troubleshooting

Table 2. Troubleshooting Guide

A guide listing common pool filter problems, their possible causes, and solutions.

Section 9. Parts List and Exploded View

9.1 Jandy CL and CV Cartridge Filter Parts List

9.2 Jandy CL and CV Filters Exploded View

LIMITED WARRANTY

WARRANTY CLAIMS

Jandy Versa-Plumb CL Series Specifications

General IconGeneral
ModelCL Series
InstallationIn-Line
Maximum Operating Pressure50 psi
MaterialPVC
Plumbing Size2 inch
Chlorine Capacity9 lbs
Connection Size2 inch
