Jandy Versa-Plumb CV580 User Manual

20 pages

To Next Page

To Next Page

Page #1 background image

Loading...

Page #1 background image

H 029 1800C

I nstallation and

O peration M anual

J andy

®

C artridge

Pool Filters

C L and C V V ersa- Plumb

™

S eries Filters

W A RN I N G

FO R Y O U R S A FE T Y - T his produc t must b e installed and serv ic ed b y a professional pool/

spa serv ic e tec hnic ian. T he proc edures in this manual must b e followed ex ac tly . I mproper

installation and/or operation can create dangerous high pressure which can cause the lter

lid to b e b lown off, possib ly c ausing death, serious inj ury or property damage. I mproper

installation and/ or operation will v oid the warranty .

B efore installing this produc t, read and follow all warning notic es and instruc tions that

accompany this lter. Failure to follow warning notices and instructions may result in

property damage, serious inj ury , or death.

C L and C V V ersa- Plumb

™

I n st a l l a t i o n a n d O p e r a t i o n D a t a

Questions and Answers:

E
Elizabeth FrenchAug 9, 2025
Why is there low water flow in my Jandy Water Filtration System?
- N
  Noah SmithAug 9, 2025
  If your Jandy Water Filtration System experiences low water flow, it could be due to several reasons. Start by checking and cleaning the filter system strainer baskets and inspecting all connections between the pool intake and the pump for air leaks. Ensure the pool water level is above the pump inlet line and that the pump is primed by filling it with water at the basket and replacing the lid. Also, inspect all lines for debris or partially closed valves, and clean or replace the filter cartridges as needed. Other potential causes include blocked pump impeller vanes (requiring a technician), broken strainer baskets (replace them), or the pump operating under speed due to low voltage (requiring a technician or electrician).
R
robert43Aug 15, 2025
How to fix water that is not clear with Jandy Water Filtration Systems?
- M
  matthewsjasonAug 15, 2025
  If the water in your pool is not clear when using a Jandy Water Filtration System, several factors could be at play. Start by checking and adjusting the disinfectant level and testing and adjusting the water chemistry. Increase the pump run time and clean the filter cartridges according to the instructions, replacing the cartridge if necessary. Also, adjust the filter time or water chemistry to address heavy bathing or dirt loads.
D
Dwayne WilsonAug 20, 2025
What to do if there is high pressure on start-up of Jandy Water Filtration Systems?
- H
  Heather OrtizAug 21, 2025
  High pressure on start-up of your Jandy Water Filtration System can be caused by a few things. It could be due to a small eyeball fitting in the pool or spa; consider replacing it with a larger diameter fitting. Another cause might be a partially closed valve on the return line, so check and fully open all valves. The pump might be too large for the system, in which case you should check the pump and filter selection. Lastly, dirty filter cartridges can cause high pressure, so clean them as per the instructions.
M
monicarubioAug 27, 2025
Why are the filter cycles short in my Jandy Water Filtration Systems?
- J
  Jean PetersAug 27, 2025
  Short filter cycles in your Jandy Water Filtration System can occur due to several reasons. It may be caused by the presence of algae clogging the filter, so check the disinfectant content. Incorrect water chemistry can also lead to this issue, so check the pH, total alkalinity, and TDS. Additionally, if the pump output exceeds the design flow rate of the filter, check the pump performance. Clean or replace the filter cartridge as per the instructions.
A
Angela SolomonSep 1, 2025
What causes dirt to return to pool with Jandy Water Filtration Systems?
- L
  Lonnie LaraSep 1, 2025
  If dirt returns to the pool when using your Jandy Water Filtration System, it's likely due to a hole in the filter cartridge or o-rings seal inside the filter. Replace the filter cartridge according to the instructions and replace the o-ring.

Jandy Versa-Plumb CV580 Specifications

General

Model	CV580
Type	Cartridge Filter
Filter Area	580 sq ft
Maximum Pressure	50 PSI
Tank Material	Fiberglass

Summary

Section 1. Safety Information

1.1 Important Safety Warning

Crucial safety precautions and warnings for operating pool equipment.

1.2 General Safety Instructions

General safety guidelines for installers and operators of pool systems.

Section 3. Installation Instructions

3.1 Filter Location

Guidance on selecting an appropriate and safe location for the filter.

3.2 Anchor Bracket Installation

3.3 Filter Preparation

3.4 Filter Plumbing

Details on connecting the filter to the pool's plumbing system.

3.5 Clamp Installation

Section 4. Start-Up and Operation

Start-Up and Operation

Step-by-step guide for safely starting up and operating the filter system.

Section 5. Filter Disassembly and Assembly

Filter Disassembly and Assembly

Section 6. Maintenance

6.1 General Maintenance

6.2 Pressure Gauge

6.3 Cleaning the Filter Cartridge

Section 8. Troubleshooting

Troubleshooting Guide

Common problems and their corresponding solutions for filter operation.
