Appendix F
Component Interconnection for
Multiple Cryodyne Cryocoolers
Figure F.1 depicts a typical multiple cryocooler
installation. As shown in this figure, an electrical power
cable is connected to each cold head; also, the
components are helium connected in parallel (all supply
fittings piped together and all return fittings piped
together). Table El in this Appendix is a generic
equipment list for components required for each
particular multiple cryocooler configuration used with a
CTI-CRYOGENICS
8500TM
Compressor. For further
assistance, contact CTI-CRYOGENICS Applications
Engineering.
