51
Configuration
Voltage measurement connection
options
The UMG604 recognises two connection
options for the voltage measurement.
Connection option 0
Direct measurement of the voltage in •
3-phase 4-conductor systems.
Measurement via 3 voltage transformers •
in 3-phase 4-conductor systems.
Connection option 1
Direct measurement of the voltage in •
three-phase 3-conductor systems.
Measurement via 2 voltage transformers •
(Aron circuit) in three-phase 3-conductor
systems.
Address Connection option
111 0 = Three-phase 4-conductor
systems (default factory
setting)
1 = three-phase 3-conductor
systems
Fig. 51.1 Section of the parameter list for the
voltage transformer connection options.

janitza UMG 604 Specifications

General

Measurement Category	CAT III 600 V
Mounting Type	DIN Rail
Voltage Measurement	Yes
Current Measurement	Yes
Frequency Measurement Range	45-65 Hz
Power Measurement	Yes
Energy Measurement	Yes
Harmonics Analysis	Yes
Communication Interfaces	Yes
Display	LCD
Operating Temperature	-10 to +55 °C
Storage Temperature	-20 to +70 °C
Device Type	Power Analyzer
Harmonics	Up to 50th
Communication Interface	RS-485
Protocols	Modbus RTU
Accuracy Class	0.5S
