Janome 15 - Inserting the Bobbin

12
Inserting the Bobbin
z Place the bobbin in the bobbin holder with the
thread running off as illustrated.
q Thread
x Guide the thread into the front notch on the
front side of the bobbin holder. Draw the thread
to the left, sliding it between the tension spring
blades.
w Front notch
e Tension spring blade
c Continue to draw the thread lightly until the
thread slips into the side notch.
r Side notch
v Pull out about 4˝ (10 cm) of thread. Attach
the hook cover plate. Check the threading by
referring to the chart shown on the hook cover
plate.
t Thread
y Hook cover plate
q
w
e
r
z
x
c
v
10
1/8
3/8
5/8
t
y
