Janome 415 - Needle Threader and Bobbin Thread Pickup

10
Drawing Up Bobbin Thread
1 Raise the presser foot and hold the needle thread
lightly with your left hand.
2 Turn the hand wheel one complete turn toward you
and raise the needle to its highest position.
Pull the needle thread to pick up a loop of the bobbin
thread.
3 Pull 15 cm (6") of both threads back and under the
presser foot.
1
2
3
Needle Threader
1
2
3 4
1 Raise the needle to its highest position.
Press down the needle threader knob as far as it will go.
The hook comes out through the needle eye from behind.
2 Pull the thread down around the thread guide then pass
it from the right and under the hook.
3 Release the knob slowly while holding the thread end
with your hand.
A loop of the thread is pulled up through the needle eye.
4 Remove the loop from the threader and pull out the
thread end from the needle eye.
Note: The needle threader can be used with a #11 to
#16 needle or Janome Blue Tipped needle.
Thread size 50 to 100 would work well.
