84
Replacing the Bobbin Holder
z Insert the bobbin holder into the hook race.
x Make sure the knob of the bobbin holder fits next to
the stopper on the race.
q Knob
w Stopper
c Replace the bobbin.
Attach the needle plate, inserting the two guide pins
into the holes in the needle plate. Tighten the screw
firmly with the screwdriver.
e Guide holes
r Screw
Replacing the Light Bulb
WARNING:
When replacing the bulb, switch off and unplug the
machine.
Wait for the light bulb to cool down before touching it.
Remove the cap and screw. Remove the face plate.
q Cap
w Screw
e Face plate
Pull the bulb out from the lamp socket.
Insert a new bulb into the lamp socket.
Attach the face plate.
r Light bulb
t Lamp socket
q
w
e
r
e
q
w
e
z
x
c
r
t
