Specifications
Desktop Robot JR3000
10.7 Output Signal (NPN)
When using an external power supply
When using an internal power supply (optional)
Assigning the wrong wiring to the I/O can damage the internal circuits.
COM-
(GND)
#genOut5 –
#genOut8
+
-
External
Device
External Power Supply DC24V
Internal Power Supply DC24V
COM +
(DC24V)
#genOut5 –
#genOut8
+
-
External
Device
67
