1.2 Installation and Connecting Cables
Note:
Be certain to comply with the instrument installation requirements
described in this manual (see page
ⅷ
). Failure to comply with these
requirements can cause faults with the instrument.
1.2.1 Preparation
Prepare a table which can bear a weight of about 50 kg (differs according to instrument) and has
an area of 700 mm (length) × 600 mm (width) when using the iRM type.
If using a PC as well, prepare a table, which can hold a weight of about 70 kg (differs according to
instrument) and has an area of 700 mm (length) × 1500 mm (width), allowing space for a printer.
Confirm that the power switch of the main unit is off and that the power switch of the PC is off
when using a PC.
1.2.2 Connecting the Cable of iRM Type
WARNING!: You may receive an electric shock if the instrument is not properly
grounded. Correctly ground the instrument using the grounding
terminal on the power board.
CAUTION: For grounding, do not use water pipes, which are often made of
nonmetals. For safety reasons, do not use gas tubing for grounding
either.
Note: Use of a 3-pin power plug with a grounding terminal is recommended.
(1) Connect the cable from the iRM to the “iRM” connector on the rear of V-600.
(2) Connect the AC power cable to the “AC INPUT” connector on the rear of V-600.
Connect the other end of the AC power cable to an electrical outlet.
1.2.3 Connecting the Cable of PC Type
WARNING!: You may receive an electric shock if the instrument is not properly
grounded. Correctly ground the instrument using the grounding
terminal on the power board.
CAUTION: For grounding, do not use water pipes, which are often made of
nonmetals. For safety reasons, do not use gas tubing for grounding
either.
Note: Use of a 3-pin power plug with a grounding terminal is recommended.
(1) Connect the “USB” port located on the rear of V-600 and the USB port on the PC using the
USB cable.
To Next Page
