4.4 Intelligent Remote Module (iRM)
Display panel
Cable
(Appearance)
Card slot
Connector for accessory
Connector for printer
(USB interface)
Connector for printer
(Parallel I/0 interface)
(Rear panel)
Figure 4.6 Intelligent remote module
Name Function
Display panel 320x240 pixel color LCD. Displays wavelength, absorbance,
measurement parameters, etc. Also used for selecting menus and
editing measurement parameters via the touch key pad.
Cable Connects to the main unit.
Card slot
Accepts a compact flash card or a flash ATA card. Card adapter is
necessary for the compact flash card.
Connector for printer
Connector for the printer (USB interface and parallel I/O interface).
Connector for
accessory
Connects to an accessory.
