TECHNICAL SPECIFICATIONS
Please Note
Due to variaons in manufactured products all claimed performance rangs, capacies, measurements,
dimensions and weights quoted are approximate only. Achievable performance and rangs when in use
can depend upon correct installaon, applicaons and use along with regular maintenance and service.
Parameter Jasic Arc 160 PFC
(JA-160PFC)
Unit Jasic Arc 180 PFC
(JA-180PFC)
Jasic Arc 200 PFC
(JA-200PFC)
Rated input voltage AC 95-230V ±15% 50/60HZ V AC 95-230V ±15% 50/60HZ AC 95-230V ±15% 50/60HZ
Rated input power
115V - 3.7
230V - 5
kVA
115V - 3.2
230V - 5.8
115V - 3.5
230V - 7.2
Rated input current Imax
115V - 32.6
230V - 21.4
A
115V - 27.5
230V - 25.3
115V - 30.1
230V - 31.3
Rated input current Ie
115V - 17.5
230V - 11.6
A
115V - 15.2
230V - 13.4
115V - 12.7
230V - 13.4
Welding current range
115V - 10 ~ 125
230V - 10 ~ 160
A
115V - 10 ~ 110
230V - 10 ~ 180
115V - 10 ~ 110
230V - 10 ~ 200
No-load voltage
115V - MMA 68
115V - TIG 9
230V - MMA 68
230V - TIG 9
V
115V - MMA 68
115V - TIG 9
230V - MMA 68
230V - TIG 9
115V - MMA 68
115V - TIG 9
230V - MMA 68
230V - TIG 9
Rated duty cycle
115V - 125A @ 35% (40°C)
230V - 160A @ 35% (40°C)
%
115V - 110A @ 35% (40°C)
230V - 180A @ 35% (40°C)
115V - 110A @ 20% (40°C)
230V - 200A @ 25% (40°C)
Eciency 85 % 85 85
Power factor 0.998 cosφ 0.998 0.998
Standard - EN60974-1 EN60974-1 EN60974-1
Protecon class IP21S IP IP21S IP21S
Insulaon class F - F F
Noise Db <70 <70 <70
Size (with handle) 365 x 135 x 280 mm 365 x 135 x 280 365 x 135 x 280
Size (without handle) mm 315 x 130 x 235 315 x 130 x 235 315 x 130 x 235
Weight 6.4 Kg 6.4 6.5
