Jasic ARC PFC Series User Manual

20
MAINTENANCE AND TROUBLESHOOTING
The following operaon requires sucient professional knowledge on electric aspects and
comprehensive safety knowledge. Make sure the input cable of the machine is disconnected
from the electricity supply and wait for 5 minutes before removing the machine covers.
Maintenance
In order to guarantee that the arc welding machine works eciently and in safety, it must be maintained
regularly. Operators should understand the maintenance methods and means of arc welding machine
operaon. This guide should enable customers to carry out simple examinaon and safeguarding by
oneself, try to reduce the fault rate and repair mes of the arc welding machine, so as to lengthen service
life of arc welding machines.
Troubleshoong
Before arc welding machines are dispatched from the factory, they have already been checked
thoroughly. The machine should not be tampered with or altered. Maintenance must be carried out
carefully. If any wire becomes loose or is misplaced, it maybe potenally dangerous to user!
Only professional maintenance personnel should repair the machine!
Ensure the power is disconnected before working on the machine. Always wait 5 minutes aer power
switch o before removing the panels.
Period Maintenance item
Daily examinaon Check the condion of the machine, mains cables, welding cables and
connecons.
Check for any warnings LEDs and machine operaon.
Monthly examinaon Disconnect from the mains supply and wait for at least 5 minutes before
removing the cover. Check internal connecons and ghten if required.
Clean the inside of the machine with a so brush and vacuum cleaner. Take
care not to remove any cables or cause damage to components. Ensure that
venlaon grills are clear. Carefully replace the covers and test the unit.
This work should be carried out by a suitably qualied competent person.
Yearly examinaon Carry out an annual service to include a safety check in accordance with the
manufacturers standard (EN 60974-1).
This work should be carried out by a suitably qualied competent person.
Descripon of fault Possible cause Acon
The welding arc cannot be
established
Power switch has not been switched ON
Incoming mains power supply is not ON
Possible internal power failure
- Switch ON power switch
- Check incoming power switch for correct supply
- Have a technician check the machine and supply
Dicult arc ignion Low arc current - Increase the arc current seng
- Check condion of the MMA welding leads
Overheat LED lit Machine operated outside duty cycle
Fan not working
- Allow the machine to cool and the unit will reset
automacally
- Have a technician check for obstrucons
blocking the fan
Over current LED lit Mains supply problem - Have a technician check the mains supply
