Autoranging Digital Multimeter
2.Description
2-1.Meter Description
1-NCV Indicate Lamp
2-2000 Count Liquid Crystal Display
3-MAX Hold Button
4-MODE Button
5-Function Switch
6-COM Input Jack
7-Positive Input Jack
8-Battery Cover
8
Autoranging
Digital Multimeter
OFF
mA
μA
V
Auto
Power
Off
Ω
V
MODEMAX
COM V Ω mA μA
200mA/600V
CAT III 300V
CAT II 600V
1
2
3 4
5
6
7
