7
Autoranging Digital Multimeter
2-2.Symbols Used on LCD Display
1-Autoranging
2-Diode Test
3-Continuity
4-Maximum
5-Battery Status
3.Button Function
3-
1.MODE Button
To select Diode/Continuity or DC/AC current.
3-2.MAX Hold Button
• The max. Hold position is used to measure the maximum value.
• The maximum measured value is up dated continuously.
•
To take a Max Hold measurement, press and release the button. To take another
Max Hold reading, press and release the button again.
6-Units of Measure List
7-Measurement Reading
8-Minus Sign
9-Alternating Current
10-Direct Current
1 2 3 4 5
6
7
8
10
9
