SECTION 6 – ELECTRICAL SYSTEM JAYCO CAMPING TRAILERS
6-6
DC FUSE PANEL LAYOUT
Below is a typical wiring layout. Your individual RV may be different.
#
Size
Function
1
—
Open
2
15 amp fuse
Bathroom Lights & Vent
3
15 amp fuse
Pump/Monitor Panel/Range Hood/Sink Lights
4
15 amp fuse
Refrigerator/Furnace
5
15 amp fuse
Bedroom
6
15 amp fuse
TV/Radio/Propane Detector
7
15 amp fuse
Ceiling Lights
8
15 amp fuse
Bunk Lights
9
15 amp fuse
Slideout Lights
10
15 amp fuse
Option
11
15 amp fuse
Option
12
20 amp auto
Slideout Motor
