SECTION 6 - ELECTRICALSYSTEM JAYCO CAMPING TRAILERS
6-10 30 AMP
APPROXIMATE ELECTRICAL LOAD RATINGS
120 Volt System
Air Conditioner 18 AMPS
Coffee Maker 6-12 AMPS
Converter (each) 8 AMPS
Curling Iron or Hair Dryer 10-14 AMPS
DVD System 3 AMPS
Microwave 12 AMPS
Refrigerator 6 AMPS
Satellite Receiver 2 AMPS
TV 2-4 AMPS
Vacuum Cleaner 8 AMPS
Washer/Dryer 12 AMPS
Water Heater 12 AMPS
120 Volts: Labeled watts divided by 120 = Power consumed in AMPS
*Momentary Load
12 Volts: Labeled watts divided by 12 = Power consumed in AMPS
12 Volt System
Aisle Lights
1.0 AMP
Baggage Compartment Lights
1.4 AMPS
Decorative Wall Lights
1.5 AMPS
Dinette Light
4.5 AMPS
Exterior Entertainment Center
5-7 AMPS
Fantastic Fan
1.5 AMPS
Fluorescent Double Lights -12”
2.0 AMPS
Fluorescent Double Lights -18”
2.5 AMPS
Furnace
12.0 AMPS
Generator Start
95.0 AMPS*
Halogen Light
1.7 AMPS
Illuminated Switch
.125 AMP
Inverter
variable
Leveling System
95.0 AMPS*
LP Detector
.125 AMP
Map Light
1.5 AMPS
Porch Light
1.5 AMPS
Power Awning
10.0 AMPS
Power Vent
5.0 AMPS
Refrigerator
3.0 AMPS
Shower Light
1.4 AMPS
Step Cover
10.0 AMPS
TV Plate/Antenna Booster
1.0 AMP
Vanity Light
4.2 AMPS
Water Heater
6.0 AMPS
Water Pump
7.0 AMPS
