36
When in alarm mode, all LEDs will ash and buzzer will beep. The Status LEDs will show
the system status.
The system performs an automatic retract. No other features are available in this mode.
○ The system automatically shuts down after (4) minutes of no operation. To reset
the system, the coach ignition be turn o, then back on, and the power
button on the Control Panel be pressed again.
○ Auto leveling cycle cannot be started until all jacks are fully retracted. Verify
jacks are retracted before attempting to auto level. (Unit will perform a full
retract automatically if jacks are down on the request of an auto cycle.)
○ System will refuse any operation when a low voltage condition is present.
○ System will automatically alarm and retract if the park brake is disengaged and
jacks are not retracted with any change in sensor readings. In alarm mode, the
only available feature is to retract all jacks.
Note WAIT display shows the status of Air/Auxiliary features.
1. The vehicle requires 12.7V DC to operate in the AUTO mode. If voltage is too low,
screen displays LOW VOLTAGE. If voltage drops below 12.7V DC, the system will
only operate in MANUAL MODE and continues to display LOW VOLTAGE.
2. Minimum Voltage – If voltage drops below 9.5 V DC during AUTO or MANUAL op-
eration LOW VOLTAGE will appear on display and system stops operating.
1. Push power button (right corner). System is operational and electronic level lights
become active.
2. Check that the Control Pad ENGAGE PARKING BRAKE is engaged.
3. Press the AUTO LEVEL button to begin the automatic leveling cycle.
4. Push the power button to de-energize the system.
1. Press power button on control panel. System is operational and power light will be lit.
2. Press DOWN ARROW to display MANUAL LEVEL on the display. Press ENTER
to set.
3. Press FRONT button until jacks contact the ground and lift front of the coach 1 to 2
inches.
4. Press REAR button until jacks contact the ground and lift the rear of the coach. Keep
the button depressed until the level indicator displays level.
5. Press LEFT or RIGHT button. If level indicator is toward left of coach, press RIGHT
button. If level indicator is toward right of the coach press LEFT button. Keep the
button depressed until level indicator displays level.
