ENGLISH
05EN
FRONT PANEL
TO DETACH THE FRONT PANEL
1. Press the release button, then the front panel will be folded
down.
2. To remove the front panel, lift it up at a little angle from hori
zontal position, then first pull out the right side and then pull
out the left side.
3. For safekeeping, store the front panel in the supplied protective
case immediately after being removed.
TO INSTALL THE FRONT PANEL
1. To install the front panel, first insert the left side into proper posi
tion then insert the right side into place.
2. When the two sides fixed into place, push the front panel into
main unit.
3. Note that if the front panel fails to lock in position properly,
pressing control button may not function and the display may
be missing some segments. Press the release button and then
reinstall the front panel again.
PRECAUTIONS WHEN HANDLING
1. Do not drop the front panel.
2. Do not put pressure on the display or control buttons when de
taching or re-installing the front panel.
3. Do not touch the contacts on the front panel or on the main unit
body. It may result in poor electrical contact.
4. If any dirt or foreign substances adhered on the contacts, they
can be removed with a clean and dry cloth.
5. Do not expose the front panel to high temperatures or direct
sunlight in anywhere.
6. Keep away any volatile agents (e.g. benzene, thinner, or insecti
cides) from touching the surface of the front panel.
7. Do not attempt to disassemble the front panel.
Release button
The left side
Front Panel
The right side
The left side
Front Panel
The right side
