5
. INSTALLING / CHANGING A PUNCH TOOL 14
NB : before engaging the new tool, make sure that pins overlapping the sheet edges are in a
retractable position (retractable pins pulled towards the operator, see picture page 13).
5.5.1. : for punching 11" sheet with 3/1" pitch, you need to retract one pin at each side of the
sheet to be perforated (pin n°7 and 34 marked in red).
5.5.2. : for punching 8
1/2"
sheet with 3/1" pitch, you need to retract one pin at each side of the
sheet to be perforated (pin n°13 and 28 marked in yellow).
5.5.3 : for punching A5 sheet with 2/1" pitch, you need to retract one pin at each side of the
sheet to be perforated (pin n°10 and 18 marked in red).
5.6 Ensure the tool is in full lock so as to be able to clamp it by turning the locking pin
clockwise.
NOTE :
To make the pin active again, the machine must be in the working position (tool up)
Unlock the closing clamp and remove the tool by the right side of the machine to reach the
retractable pins.
A mechanical catch stops the tool inside the machine.
