JBL 1500 - Daughter PCB Components; Main PCB Components

Part numbe
r
Qt
y
Description Reference Designato
r
FUSE PCB
043-324300-000ZR 1 GR INDUCTOR 324uH YT-10778 L13
025-006000-000ZR 1 GR Thermister P/N:CL-60 TH3
POWER PCB
Capacitors
032-100484-200ZS 3 GS END Mylar cap. 1uF/250V K P:15 C410,418,427
034-680794-200ZR 4 GR Elec. Cap. (LP) 85℃ 6800uF/80V M (R)3050 P:10 C420-423,
030-180384-300ZR 1 GR Ceramic cap. 180pF/250V K X7R P:5 C419( in series with R403 T400 pin2-5)
031-220364-100ZS 1 GS SMD Cap. 0u22/100V K 1206 X7R C424
031-100384-100RZS 2 GS SMD cap.0u1/250V K 1206 X7R C428,429
031-100344-102AZS 4 GS SMD cap. 0u1/50V K 1206 X7R C417,401-403,
031-100244-101ZS 3 GS SMD cap. 0u01/50V K 1206 X7R C404-406
034-220625-300ZS 2 GS electrolytic cap. 220uF/25V M (R)0812 P:5 C414,413
034-330625-300ZS 1 GS elec. Cap. 330uF/25V M (R)1013 P:5 C412
034-470415-300ZS 1 GS electrolytic cap. 4u7/50V M (R)0511 P:2.0 C407
034-470515-200ZR 1 GR elec. Cap. 47uF/16V M (R)0511 P:2.5 C408
034-220516-301ZS 6 GS electrolytic cap. 22uF/16V M (R)0511 P:2 C223,416,14,15,411,415
035-100464-300ZR 2 GR ESK mylar cap. 1u/100V K P:5 C425,426
Resistors
028-100301-020ZR 1 GR FUSIBLE RES 100R 1W J R403(C419 in sereis with C403 T400 pin2-5)
024-910498-120ZS 2 GS SMD resistor 9K1 1/8W J 0805 R413,415
024-470398-121ZS 2 GS SMD resistor 470R 1/4W J 1206 R401,402
024-100598-101ZS 4 GS SMD resistor PN:1206F103 10K 1/4W F 1206 R409,416,417,405
024-220498-120ZS 1 GS SMD resistor 2K2 1/4W J 1206 R400
Semiconductors
054-008407-000ZR 3
GR SMD ZEN DIODE:(PHILIPS) PN:BZX84C15-7-F SOT-23
D400,402,403
054-000100-100ZR 4 GR GS SMD DIODE: PN:ES1D 200V 1A (PANJIT) D406-409
050-013000-100 1 DIODE TVZ:DIP PN:P6KE130A (CONCORD) D404
051-000600-100ZR 1 GR transistor NPN PN:MPSW06RLRA TO-92 (ON) Q406
051-005600-100ZR 1 GR transistor PNP PN:MPSW56RLRAR TO-92 (ON Q408
051-003100-000ZS 1 GS transistor NPN PN:TIP 31C TO-220 (MOSPEC) Q404
054-390402-100ZR 1
GR SMD Transistor (SC00044) PN:MMBT3904TR(Fairchild) Q402
052-150400-000ZR 1 GR bridge rectifier PN:GBJ1504 BR400
053-010200-000 1 IC:DIP PN:TOP102YAI (PWM Switch) U400
Miscellaneous
044-100100-000ZS 3 GS SMD FERRITE BEAD PN:321611 600R/100MHz 1206 FB403-405
044-100103-000ZS 1 GS SMD FERRITE BEAD PN:321611 800R/100MHz 1206 FB406
043-560200-000ZR 1 GR INDUCTOR 56uH YT-10779 L400
072-040064-000ZR 2 GR Terminal (PCB TYPE) PC250 (t=0.8m/m) T250MA TER401,404
042-010115-000ZR 1 GR X'former PN:YT-13167 KAPPA-1000 T400
DAUGHTER PCB (Attached to Power PCB
)
054-033904-100ZR 1 SMD (TRANSISTOR) PN:MMBT3904LT1G SOT23 ING Q403B
054-033906-100ZR 1 SMD transistor (ON) PN:MMBT3906LT1G SOT23 ING Q405B
054-414803-100ZS 1 GS SMD DIODE:PN:LL4148 MINI-MELF ING D410B
024-100598-120ZS 2 GS SMD resistor 10K 1/8W J 0805 ING R404B,R407B
024-220298-120ZS 1 GS SMD resistor 22R 1/8W J 0805 ING R412B
034-100444-300ZR 1 GR electrolytic cap. 1uF/50V K (R)0511 P:5 TAING C430B
072-040337-000ZR 1 HEADER Right Angle PN:211-110-000-400 10PIN CONNECT
MAIN PCB
Resistors
024-100498-120ZS 1 GS SMD resistor 1K 1/8W J 0805 R119
024-100598-120ZS 17 GS SMD resistor 10K 1/8W J 0805 R1,4,7,16,121-123,126,128,138,165,168,170,125,143,169,19,
024-100698-120ZS 1 GS SMD resistor 100K 1/8W J 0805 R120
024-130598-120ZS 1 GS SMD resistor 13K 1/8W J 0805 R118
13
1500 Array Subwoofer
