JBL 1500 - Mechanical Parts Details; Mechanical Parts Listing

Part numbe
r
Qt
y
Description Reference Designato
r
MAIN PCB
024-150598-100ZS 2 GS SMD resistor 15K 1/8W F 0805 R20,21
024-220298-121ZS 2 GS SMD resistor 22R 1/4W J 1206 R28,29
024-220498-121ZS 4 GS SMD resistor 2K2 1/8W J 0805 R17,31,110,139
024-220598-120ZS 1 GS SMD resistor 22K 1/8W J 0805 R127
024-332498-100ZS 1 GS SMD resistor 3K32 1/8W F 0805 R22
024-332598-101ZS 2 GS SMD resistor 33K2 1/8W F 0805 R60,60B
024-392498-100ZR 1 GR SMD resistor 3K92 1/8W F 0805 R63
024-470398-120ZS 4 GS SMD resistor 470R 1/8W J 0805 R145,155,177,186
024-470598-120ZS 2 GS SMD resistor 47K 1/8W J 0805 R3,171
024-560298-120ZS 4 GS SMD resistor 56R 1/8W J 0805 R24-27
024-560498-120ZS 1 GS SMD resistor 5K6 1/8W J 0805 R30
024-560598-120ZS 1 GS SMD resistor 56K 1/8W J 0805 R15
024-680498-120ZS 1 GS SMD resistor 6K8 1/8W J 0805 R23
Capacitors
031-100144-103ZS 1 GS SMD cap. 0u001/50V K 0805 X7R C130
031-100144-106ZS 2 GS SMD cap. 0u01/50V K 0805 X7R C27,28
031-100344-100ZS 1 GS SMD cap. 0u1/50V K 0805 X7R C116
031-100364-100ZS 7 GS SMD cap. 0u1/100V K 1206 X7R C5,6,69,112,115,135,138
031-100384-100RZS 1 GS SMD cap. 0u1/250V K 1206 X7R C39B
031-220344-300ZS 1 GS SMD cap. 220pF/50V K 0805 NPO C40
031-470144-101ZS 1 GS SMD cap. 0u0047/50V K 0805 X7R C1G1
031-470344-100ZS 1 GS SMD cap. 470pF/50V K 0805 X7R C123
034-100715-300ZS 2 GS elect. Cap. 1000uF/16V M (R)1017 P:3.5 C109,132
034-330615-301ZS 1 GS elec. Cap. 330uF/16V M (R)0812 P:3.5 loose package C32
032-100484-200ZS 5 GS END mylar cap. 1uF/250V K P:15 C30,37,39,C31,38
033-330494-270ZS 2 GS NPE cap. ELYTONE 3u3/63V K10 (R) 8x13 TBE C114,137
033-680464-270ZS 2 GS NPE cap. 印ELYTONE 6u8/100V K10 (R)1020 GNE C113,136
034-820794-200ZR 2 GR elec. Cap. (LP) 85℃ 8200uF/80V M (R)3545 P:10 C1,4
034-100625-300ZS 1 GS elect. Cap. 100uF/25V M (R)6.3x11 P:5 C62
034-220525-300ZR 2 GR elec. Cap. 22uF/25V M (R)5x11 P:2.5 TAPIN C25,26
034-220615-300ZS 1 GS elect. Cap. 220uF/16V M (R)0611 P:2.5 C8
034-220625-300ZS 1 GS elec. Cap. 220uF/25V M (R)0812 P:5 C100
Resistors
021-100402-021ZS 2 GS MOF resistor 1K 2W J FK TYPE R173,48
022-005105-020ZS 1 GS resistor PN:SQM 0R05 5W J 25x13 R2
020-220496-100ZS 1 GS film resistor 2K2 1/2W J R6
Semiconductors
054-000100-100ZS 5 GS SMD DIODE: PN:ES1D 200V 1A D23,37,40,44,47
054-008409-000ZR 1
GR SMD ZENER DIODE:(PHILIPS) BZX84C3V0-7-F SOT-23
D32
054-033904-100ZR 7 GR SMD (TRANSISTOR) PN:MMBT3904LT1G SOT23 Q28,29,50,51,127,128,130
054-033906-100ZR 2 GR SMD transistor (ON) PN:MMBT3906LT1G SOT23 Q30,38
054-290701-100ZR 1 GR SMD transistor (ON) PN:MMBT2907ALT1 SOT-23 Q52
054-414803-100ZS 15 GS SMD DIODE:PN:LL4148 MINI-MELF D1,4-6,21,22,31,33,34,38,41,45,48,53,54
054-540100-100ZR 3
GR SMD transistor PNP (ON SEN) MMBT5401 LT1 SOT-23
Q1,2,26
054-555100-100ZR 1 GR SMD transistor (NPN) PN:MMBT5551 LT1R (ON) Q25
051-359400-000ZR 4 GR MOSFET N-CHANNEL PN:2SK3594-01SC (FUJI) Q11,13,15,17
051-290700-100ZR 4 GR Transistor PNP (ON) PN:MPS2907A RLRAR TO-92 Q12,14,16,18
051-540101-000ZR 1 GR Transistor PNP(FAIRCHILD PN:2N5401 TO-92 Q3
Miscellaneous
072-040039-000ZR 8 GR terminal (PCB TYPE) PC205 (t=0.8m/m) T205MA TER402,403,406,407,TER2,4,8,3
044-100100-000ZS 2 GS SMD FERRITE BEAD PN:321611 600R/100MHz 1206 FB1,2
025-010300-000ZR 1 GR thermister PN:NTSE103KZ072 K L:50mm TH1
025-210100-000ZS 1 GS thermister (PTC) PN:PTMS2101RP516Y TH2
043-110300-000ZR 1 GR COIL PN:YT-13141 110uHx2±10% L8 (L8+L11)
043-300101-000ZR 2 GR INDUCTOR PN:YT-10033 30uH L9,10
043-560200-000ZR 1 GR INDUCTOR 56uH YT-10779 L12
072-040007-000ZS 1 GS terminal housing SWA101 PN:JS-1001-07 7P P9
072-040008-110ZS 1 GS terminal housing PN:JS-1001-08 8P P:2.5 P1
072-040064-000ZR 2 GR terminal (PCB TYPE) PC250 (t=0.8m/m) T250MA T1,TER7
073-111003-000ZR 1 GR shorting strap 54.9x13.6x1mm J7
14
1500 Array Subwoofer
